Pleated Disposable Panel Filters

Description

Our professional Pleated Disposable Panel Filters have higher efficiency and capacity than the similar-sized glass fibre panel filters or the synthetic Panel Filters

Disposable Panel Filters

The Disposable Panel Filters core consists of a reinforced non-woven media which is bonded to an expanded metal support grid which is then Pleated, increasing the filtration surface area by up to 3 times that of the face area. This means that the Pleated Panel Filters will handle significantly higher air volumes with low-pressure loss, thus saving on energy and running costs

Also available: Filter media achieving grades F5 – F8, Panel Filter sizes can be manufactured to any specific requirements. For more details please contact us

Pleated Filters Type AP (Grade G4 to BS EN779)

Measure your existing Pleated Filters accurately in ‘mm‘ and then enter the precise dimensions in the boxes below followed by the quantity required

Non-Standard/Custom Size (mm) Height – Width – Depth

Please note, due to manufacturing limitations:
Minimum filter size Height 150mm x Width 150mm
Maximum filter size Height 600mm x Width 650mm
Depth: 20, 22, 25, 38, 45,48, 51, 90, 95, 98, 100mm

CUSTOM SIZE ORDERS

If your dimensions fall outside these sizes please contact sales@acefiltration.co.uk or 01474 325666.

Download specification and data sheet
